Products Wire Mesh Roll
Wire Mesh Rollသံဇကာလိပ်
Four openings, each with its own roll length, width and wire range.
Specification
We offer four specifications of wire mesh roll: 5⁄8" x 5⁄8", 1" x 1", 1.25" x 1.25" and 2" x 2".
| Length | Width | Wire Size |
|---|---|---|
| 10 m to 20 m | 3' | 0.7 mm to 1.2 mm |
| 10 m to 20 m | 4' | 0.7 mm to 1.2 mm |
| Length | Width | Wire Size |
|---|---|---|
| 8 m to 15 m | 3' | 1.2 mm to 2.1 mm |
| 8 m to 15 m | 4' | 1.2 mm to 2.1 mm |
| 8 m to 15 m | 5' | 1.2 mm to 2.1 mm |
| 8 m to 15 m | 6' | 1.2 mm to 2.1 mm |
| Length | Width | Wire Size |
|---|---|---|
| 10 m to 15 m | 3' | 1.2 mm to 2.1 mm |
| 10 m to 15 m | 4' | 1.2 mm to 2.1 mm |
| 10 m to 15 m | 5' | 1.2 mm to 2.1 mm |
| 10 m to 15 m | 6' | 1.2 mm to 2.1 mm |
| Length | Width | Wire Size |
|---|---|---|
| 15 m to 25 m | 6' | 2.1 mm to 3.2 mm |
Openings at true scale
Four openings, side by side.
Each is stroked at the thinnest wire published for that opening, so opening and wire are both true against each other.
Openings to relative scale · wire at the thinnest published for each opening
